Discontinued

Intelligent Auto Backwash Water Filter 1 1/2in BSPM, 89um

Model No: IAB40

WHERE TO BUY

Impurities such as sand, rust flakes, lime deposits and coarse material can damage the water distribution line and household / office appliances (pipes, valves, mixers, faucets, washing machines, etc.). The installation of a protection filter is the most simple and efficient option to avoid such problems. Puretec IAB is an automatic self-cleaning filter, robust and compact, with brushing system for the cleaning of the cartridge and discharge valve for dirt.

Specifications

Ordering Code
IAB40
Micron Rating
89 Micron
Connection
1½"
Flow Rate
150 Lpm
Min/Max Pressure
150 - 1600˜ kPa
Min/Max Water Temperature
0 - 30°C (32 - 86°F) Protect from freezing
Min/Max Ambient Temperature
0 - 40°C (32 - 104°F) Protect from freezing
Power Supply
230V AC / 50 Hz
Warranty
1 year^
*Micron rating is nominal. ˜If pressure exceeds max pressure, an approved pressure limiting device needs to be fitted. Note: Check local plumbing regulations as a specific kPa limit for the pressure limiting valve may be required (in particular, The Australian & New Zealand Plumbing Standards. Ref. AS/NZS 3500.1:2021, Clause 3.3.4). If water hammer is present, fit a hammer arrestor close to the source of the hammer.

Features & Benefits

  • •Program backwash intervals from hours to days 12/24/36/48 hours.
  • •Single touch button manual override to backwash on demand at any time.
  • •Stainless steel net filtering surface is resistant to mechanical shock and pressure gradients.
  • •Cleaning brushes are equipped with Silver to inhibit bacterial growth.
  • •Simple initial set-up.
  • •Set and forget cycles.
  • •Brass head means it’s tough and resistant to mechanical shear stresses.
  • •High strength Trogamid discharge valve.
  • •Two dry contacts for external equipment such as monitoring, solenoids etc.
  • •Compatible with WTV5092 differential pressure switch.
  • •Twin pressure gauges to monitor pressure drop.
