IMB50+ Backwash filter

  • •Manual Backwash filter system

  • •Reduces sediment, silt and sand

  • •100 micron, 2" connection, 236 Lpm

Price: $1,416.74 INC GST*

Model No: IMB50W

WHERE TO BUY

Puretec IMB+ Series is an innovative filter with a patented system of cleaning composed of two different actions: brushing of the filtering cartridge and high speed discharge. This method allows an efficient and thorough cleaning both of the filtering cartridge and the filter bowl. The cleaning is started by rotating clockwise the upper grey knob: this movement activates, at each click, the brushing system and the opening of the discharge valve which creates a high-speed tangential flow that removes impurities accumulated in the filter bowl.

Specifications

Ordering Code
IMB50W
Micron Rating
100 Micron*
Connection
2” BSPM
Nominal Flow Rate
237 Lpm
Min/Max Pressure
150 - 1000 kPa
Min Pressure for Backwashing
250 kPa
Min/Max Temperature
5 - 30°C
Water Consumption During Backwashing:
14 L
Power Supply
Not needed
Warranty
1 year^
Protect from freezing. *Micron rating is nominal. ~If the pressure exceeds max pressure, an approved pressure-limiting device needs to be fitted. Note: Check local plumbing regulations as a specific kPa limit for the pressurelimiting valve may be required (in particular, The Australian & New Zealand Plumbing Standards. Ref. AS/NZS 3500.1:2021, Clause 3.3.4). If a water hammer is present, fit a hammer arrestor close to the source of thehammer. ^Warranties in this document cover parts for the period stated and include cover for parts and labour for the first year where applicable, subject to approval.

Features & Benefits

  • •Brass head means it’s tough and resistant to mechanical shear stresses.
  • •Stainless steel net filtering surface is resistant to mechanical shock and pressure gradients.
  • •Cleaning brushes are equipped with Silver to inhibit bacterial growth.
  • •Easy to use large turn and click knob to engage backwash function.
