Hybrid R4 High Flow UV System, 130L/min Reversible Bracket

Price: $2,777.36 INC GST*

Model No: HYBRID-R4-LF

WHERE TO BUY

This system removes* sediment, silt, sludge, dirt, rust, coarse & fine particles and is highly effective in eliminating bacteria and parasites in your water. This system has higher capacity and longer life filter cartridges compared to Hybrid R2.

Suited to medium to large applications that requires higher capacity and longer life filter cartridges. This system is designed for both mains and rainwater supply. This unit can be installed from left to right or right to left depending on the installation requirements.


*'Removes' indicates significant reduction, not necessarily 100% removal.

Specifications

Model No
HYBRID-R4-LF
Replacement Parts and Cartridges
Stage 1 filtration
PL20MP2
Stage 2 filtration
PX01MP2
UV Lamp
RL6
Flow rate @40mJ/cm²:
54 Lpm
Flow rate @30mJ/cm²:
70 Lpm
Flow rate @16mJ/cm²:
130 Lpm
Connection
1" BSP [25mm]
Warranty
3 years^
Important Note: Use only genuine Puretec replacement cartridges. Flow rate @30mJ/cm² is the industry standard for drinking water. Puretec Hybrid UV systems are designed for common rainwater. The effectiveness of a UV system is dependent on the clarity of water present. If you are unsure of the clarity of your water Puretec can arrange a UVT test to verify that no further filtration is required before the UV. Contact Puretec on 1300 140 140 (AU) or 0800 130 140 (NZ) for further information on this.

Features & Benefits

  • •Dual filtration for extra sediment capacity.
  • •Filtration and ultraviolet all in one unit.
  • •Reversible aluminium mounting bracket for easy installation.
  • •Made from lightweight, durable materials.
  • •Equipped with a lamp count-down timer and alarm.
  • •Anti-corrosion construction.
  • •1” connections.
  • •Quick and easy plug-and-play installation.
