S/Steel Housing, SS316, 10" x 2.5" - 1" conn
Price: $1,215.52 INC GST*
Model No: TSI-251-316
WHERE TO BUY
Puretec TSI-251-316 Stainless Steel Housing
316 Stainless Steel, Size 2.5” x 10”, 1” BSPT Connection
MAINTENANCE MADNESS PROMO
Purchase any participating product and get the matching maintenance kit or replacement cartridge FREE!Click Here
Price: $1,215.52 INC GST*
Model No: TSI-251-316
WHERE TO BUY
The Puretec TSI-251-316 Series stainless steel filter housings offer a range of solutions for your heavy-duty filtration needs. Simple to install and maintain, these housings are ideal for schools, restaurants, farms and industrial use.
These heavy-duty housings can be used on cold and hot water lines up to a maximum of 80°C.
This housing can be used in a wide variety of applications and is compatible with a wide range of water filter cartridges (sold separately). Select a cartridge that best suits your situation/water source. For cartridge, and selection advice contact your local Puretec dealer or call our Puretec Customer Service Helpline.
These heavy-duty housings can be used on cold and hot water lines up to a maximum of 80°C.
This housing can be used in a wide variety of applications and is compatible with a wide range of water filter cartridges (sold separately). Select a cartridge that best suits your situation/water source. For cartridge, and selection advice contact your local Puretec dealer or call our Puretec Customer Service Helpline.
Specifications
Ordering Code
TSI-251-316
Material of Construction
316 Stainless Steel
Cartridge Size
2.5” x 10”
Flow Rate
19 Lpm*
Inlet/Outlet Connection
1” BSPT
Vent Connection
¼” BSPT
Drain Connection
¼” BSPT
Min/Max Pressure
200 - 1034˜ kPa
Min/Max Temperature
0 - 60°C @300ppm chloride,
0 - 80°C @150ppm chloride,
(protect from freezing)
Max. Chloride Content
300 ppm
Warranty
1 year^
^Warranty is 1-year parts and labour. *Flow rate is dependent on filter cartridge used. The application should be designed according to filter cartridge capabilities. ˜If pressure exceeds max pressure, an approved pressure limiting device needs to be fitted. If a water hammer is present, fit a hammer arrestor close to the source of the hammer. Note: Check local plumbing regulations as a specific kPa limit for the pressure limiting valve may be required (in particular, The Australian & New Zealand Plumbing Standards. Ref. AS/NZS 3500.1:2021, Clause 3.3.4)
Features & Benefits
- •Heavy duty construction - designed for installations in the most rugged conditions.
- •316 stainless steel housing as standard polished internally and externally.
- •Quick release clamp for simple cartridge removal.
- •Can withstand temperatures up to a maximum of 80°C.
